The ‘Duty’ series is the more affordable series. At its heart lies a 223cc oil-cooled single cylinder engine that generates 16.8bhp and 17Nm. It opts for a five-speed gearbox. Suspension comprises of 41mm front forks and twin shock absorbers at the rear. The engine comes coupled to a 5-speed gearbox which transmits the power to the rear wheel via chain drive. UM Renegade Duty Ace features 41mm conventional telescopic forks with black covers and twin-hydraulic spring suspension at the rear. Braking duties are handled by 280mm two-piston calliper at the front and a 220mm disc at the rear.
Specifications
Transmission
| No Of Gears : | 5-Speed |
Brakes
| Brakes Front : | Disc |
| Brakes Rear : | Drum |
Chassis and Suspension
| Suspension-Front : | Hydraulic Telescopic |
| Suspension-Rear : | Hydraulic With Spring |
Tyres and Wheels
| Tyre Size (Front) : | 120/80-17 |
| Tyre Size (Rear) : | 130/90-15 |
| Wheel Size : | Front :-17 inch, Rear :-15 inch |
| Tyre Type : | Tubeless |
Dimensions
| Length*Width*Height : | 1972*730*1135 |
| Wheelbase(mm) : | 1360 mm |
| Ground Clearance (mm) : | 180 mm |
| Fuel Capacity (Litres) : | 10 L |
| Kerb Weight : | 140 kg |
Electricals
| Head Lamp : | Halogen |
Service Cost
| Air Filter Service Cost : | N |
| Spark Plug Service Cost : | N |
